Ovonic D15 Dual 15W 1.2A LiPo Balance Charger for 1S-3S 3.7V-11.1V Lipo Battery

Ovonic D15 Dual 15W 1.2A LiPo Balance Charger for 1S-3S 3.7V-11.1V Lipo Battery

Name: Ovonic D15 Dual 15W 1.2A LiPo Balance Charger for 1S-3S 3.7V-11.1V Lipo Battery
Brand: Ovonicshop
SKU: O-CHARGER-D15
Price: 42.99 USD
Availability: OutOfStock

Sold out

$47.99 AUD

$42.99 AUD

Ship From

Australia Warehouse

For Australia Customers: Please select AU warehouse before adding to cart

Free shipping on order over AUD$99(About USD$73) for AU, SG, MY, TH, JP, KR, UA, KZ,etc.

Quantity

Description

Why choose us

Unleash the power of efficient charging with the OVONIC D15 Dual 15W+15W 1.2A Charger, specially designed for 1~3S 3.7V-11.1V Lipo batteries. This Upgraded Version charger is a game-changer, allowing you to charge two batteries simultaneously with ease.

Key Features:

🔋 Dual Channel Capability: Charge 1S-3S lipo batteries with balance charge functionality, now upgraded to handle two batteries at once.
🔋 Power Charging effective: Delivering up to 15W of charging power at a current rate of 100-1200mA per channel, with a max. of 1.2A, significantly reducing charging times.
🔋 User-Friendly: XHR plug output， Plug & Charge make it convenience； automatic power-off function when charging is complete.
🔋 Safety First: Built-in power management module with high balancing accuracy guarantees a more stable and secure charging process.
🔋 Compact & Portable: Small and lightweight design makes it your perfect on-the-go charging companion.

Specification of Ovonic D15 Dual Lipo Charger:

Product Model	D15
Input Voltage	100-240V/AC
Output Current	100-1200mA
Display	1 Green/Red LEDS
Dimensions	1008034.5mm
Net Weight	Approx. 165g
Power	15W*2
Current	Maximum Current 1.2A (Average Current 0.8A)
Full Charge Voltage	Active balancing, 5%+21mV (4.2*5/1000=21mV)
Compatible Batteries	1s-3s LiPo, 3.7V-11.1V
Battery Error Detection	Voltage differential >350mV, Voltage < 2.5V, Voltage > 4.25V, Cell damage, Poor contact
Charge Time Test	2200mAh 3S battery: 2-hour full charge time (charges at 18.33mAh per minute), 7200mAh 2S battery: 6.5-hour full charge time (charges at 18.46mAh per minute)
Blinking Logic	Green Flashing three times - Power Connected, Red Flashing - Charging, Solid Green Light - Full Charged, Solid Red Light - Error Warning
Power Management	Yes (to achieve better balance, there is basically no voltage difference when fully charged)
Safety Test	AC and DC withstand voltage test, ground resistance test, insulation resistance test, leakage current test
Package Inclued	1× D15 Dual Lipo Charger, 1× AC Input Cabel, 1× User Manual

Potential Use Cases:

RC Hobbyists: Whether you're into RC cars, boats, airplanes, or drones, OVONIC D15 Dual LiPo Charger is an essential tool for keeping your batteries charged and ready for your next thrilling adventure.
Professional Applications: From professional drone pilots to industrial equipment operators, the D15 offers a reliable and efficient charging solution for a wide range of professional applications.
Enthusiasts: Whether you're a casual user or a dedicated enthusiast, this charger provides the convenience and performance needed to keep your LiPo batteries in peak condition.

Overall, Ovonic D15 with its dual charging capability, intelligent balance charging, and compact design, it's the perfect companion for anyone who relies on LiPo batteries for their electronic devices. This advanced charger is designed to provide efficient and reliable charging for 1-3S Lipo batteries, making it an essential tool for RC hobbyists, drone enthusiasts, and anyone else who relies on lipo batteries for their devices.

Downward file: User's Guide
